Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
File Device View Options Help
Display
Yt Diagram
Outputs/Inputs
Device Status
-----------------------------------
Toolbar
Status Bar
-----------------------------------
Update
1
Status
Overview
• Primary variable out of
limits
• Non-primary variable out
of limits
• Analog Output outside the
operating range limits
• Analog Output in fixed
mode
• Cold start
• Configuration changed
• Field device malfunction
I/O
• Calibration Data Lost
• 20mA Analog Input HW
Error
• Underrun analog input 1
• Overrun analog input 1
• Underrun analog input 2
• Overrun analog input 2
• Current Output Overrange
• Pulse Output Overrange
• Current Output in fixed
mode
• Pulse Output in fixed
mode
Sensor
• Sensor open
• Sensor short circuit
• Path 1 Signal Failure
• …
• Path 3 Signal Failure Device Status
• Unreliable
• Empty Pipe Error
• Signal Proc. Contr. Error
• Peripheral Contr. Error
• HW error frontend
• Communication error
• EEPROM R/W Error
• Checks. err. service par.
• Checks. err. menu par.
• Simulation mode active
• Restart
Totalizers
• Totalizer Overrun Error
• Totalizer Storage Error
• PRimary flow Overrun
Error
• SECondary flow Overrun
Error
2
UFC 030 HART Menu Tree PDM
Menu Bar
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Loc Local PDM, affects only PDM views
Device
Device Info
• Manufacturer
Rd
• Model Number Rd
• Serial Number Rd
• µP1 HW No. Rd
• µP2 SW No. Rd
• FE HW No. Rd
• DSP HW No. Rd
• DSP SW No. Rd
HART IDs
• Tag
• Manufacturer
Rd
• Device Type Rd
• HART Device ID Rd
• Universal Revision Rd
• Device Revision Rd
• Software Revision Rd
• Hardware Revision Rd
• Date Rd
• Final Assembly No. Rd
• Sensor Serial No. Rd
