Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
Configure
Compare
Clear Offline
-----------------------------------
Status/Conditions
Process Variables
Scan Device
-----------------------------------
Calibration Management
Diagnostics and Test
Calibrate
Reset
Paramter Protection
-----------------------------------
Rename
Unassign
Assign / Replace
-----------------------------------
Audit Trail
Record Manual Event
Drawings / Notes ...
Help ...
Overview
• Primary variable out of
limits
• Non-primary variable out
of limits
• Primary variable analog
output saturated
• Primary variable analog
output fixed
• Cold start
• Configuration changed
• Field device malfunction
Sensor / Device
• Path 1 Signal Failure
• …
• Path 3 Signal Failure
• Sensor open
• Sensor short circuit
• Unreliable
• Empty Pipe Error
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Loc Local AMS, affects only AMS views
UFC 030 HART Menu Tree AMS
IO / Totalizers
• Underrun analog input 1
• Overrun analog input 1
• Underrun analog input 2
• Overrun analog input 2
• 20mA Analog Input HW
Error
• Calibration Data Lost
• Current Output Overrange
• Current Output in fixed
mode
• Pulse Output Overrange
• Pulse Output in fixed
mode
Raw Values
• Relative
Flow Speed 1 ... 3 Opt
• SOS 1 ... 3 Opt
• Gain 1 ... 3 Opt
• Signal Proc. Contr. Error
• Peripheral Contr. Error
• HW error frontend
• Communication error
• EEPROM R/W Error
• Checks. err. service par.
• Checks. err. menu par.
• Simulation mode active
• Restart
• Totalizer Overrun Error
• Totalizer Storage Error
• PRimary flow Overrun
Error
• SECondary flow Overrun
Error
Process Values
• Actual Flow
• Corrected Flow
Opt
• VOS
Correction
• Analog Input 1
Opt
• Analog Input 2 Opt
Additional Values
• F/R Indication
• Gain
Totalizers
• Totalizer 1
Opt
• Totalizer 2 Opt
• Totalizer Sum Opt
Current Output
• Value
• Percent of Range
Pulse Output P
• Value
Opt
• Percent of Range Opt
Device
• Tag
• Descriptor
Opt
HART
• Polling Address
• Device ID
1
2
