Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
1 Dynamic
Variables
2 Configuration /
Test
3 Quit/Reset
4 HART Variables
1 Function P Opt
2 Direction P Opt
3 Digital Output Opt
4 Trip.Point 1 Opt
5 Trip.Point 2 Opt
6 Time Constant Opt
7 Output Opt
8 Pulserate Units Opt
9 Pulsrate Opt
10 Units
Pulse/Unit Opt
11 Pulse/Unit Opt
12 Pulswidth Opt
1 Test / Info
2 Installation
3 Service Menu
4
5
1
1
1 Flow
2 Version
3 Display
4 Current Output I
5 Pulse Output P
6 User Data
1
1 Language
2 Entry Code 1
3 tag
4 Text Volume
5 Text Time
6 Unit Volume
7 Unit Time
8 Enable Reset
9 Error Limit
10 Counter
Decrement
11 Counter Limit
1 Function I
2 Direction I
3 Range I
4 I 0%
5 I 100%
6 Limit
KROHNE UFC030 HA 45e70201 (3/5)
05/04
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Loc Local HC275/FC375,
affects only HC275/FC375 views
UFC 030 HART Menu Tree HC275 / FC375
