Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
1 Dynamic
Variables
2 Configuration /
Test
3 Quit/Reset
4 HART Variables
1 Reset Menu Par.
2 Reset Service Par.
3 Reset Calib. Par.
4 Reset All Par.
5 Reset Factory Par.
6 Meter Size Table
7 Version
1 Test / Info
2 Installation
3 Service Menu
4
1
1
1 Service Code
2 System
Opt
3 Current Output I
Opt
4 Sensor Opt
5 Measuring Path Opt
6 An. Inp. Calib. Opt
7 Device
Information Opt
8 Raw Values Opt
1 Calibrate Analog
Input 1
2 Calibrate Analog
Input 2
3 Input 1 0mA
4 Input 1 20mA
5 Input 2 0mA
6 Input 2 20mA
1 Calibration 4 mA
2 Calibration 20 mA
3 Calibrate Current
Output I
1 Dead Time
2 Trigger Select
3 Trigger Level 1
4 Trigger Margin
5 Sensor Frequency
6 Zero Value Path 1
....
2, 3
1 Select Path
2 Weight 1
...
5 Calibrate Path
6 Length 1
...
9 T. Window Start
10 T. Window End 1 Path 1 active
...
1 Manufacturer
2 Model No.
3 Serial Number
Rd
4 µP2 HW No.
5 Front end HW No.
6 DSP HW No.
7 Available I/O
1 SI units
2 Pulse Output
3 Current Output
4 Digital Input
5 Analog IO module
6 HART Interface
Rd
7 FF Interface Rd
8 PA Interface Rd
9 MODIS Version Rd
1 Rel. Flow Speed 1
...
4 SOS 1
...
7 Gain 1
...
KROHNE UFC030 HA 45e70201 (5/5)
05/04
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Loc Local HC275/FC375,
affects only HC275/FC375 views
UFC 030 HART Menu Tree HC275 / FC375
