Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
Attachment B
Configure
Compare
Clear Offline
-----------------------------------
Status/Conditions
Process Variables
Scan Device
-----------------------------------
Calibration Management
Diagnostics and Test
Calibrate
Reset
Paramter Protection
-----------------------------------
Rename
Unassign
Assign / Replace
-----------------------------------
Audit Trail
Record Manual Event
Drawings / Notes ...
Help ...
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Loc Local AMS, affects only AMS views
UFC 030 HART Menu Tree AMS
Basic Setup
Sensor
• Zero Value
• Flow Direction
Process Input
• Flow Units
• Full Scale
• Master TC
• L.F. Cutoff
• Cutoff on
Opt
• Cutoff off Opt
Correction
• Converter Function
Current / Pulse Output
• Function I
• Range I
• Function P
Opt
• Output Opt
Display
• Function Totalizer
• Display Totalizer
Sensor
Meter
• Meter Size Table
Opt
• Meter Size Units Opt
• Meter Size
• GK Value
Volume Flow Limits
• Upper Sensor Limit
Rd
• Minimum Span Rd
Heat Flow Limits Opt
• Upper Sensor Limit Rd
• Minimum Span Rd
• Zero Value
• Flow Direction
Sensor Opt
• Dead Time
• Trigger Select
• Trigger Level 1
• Trigger Margin
• Sensor Frequency
Correction
Version
• Converter Function
• Temperature Units
Opt
• Input 1 4mA Opt
• Input 1 20mA Opt
• Pressure Units Opt
• Input 2 4mA Opt
• Input 2 20mA Opt
• K0 Opt
• K1 Opt
• K2 Opt
• Density 15 Opt
• Heat Flow Units Opt
• Full Scale Opt
Analog Input Calibration Opt
• Input 1 0mA
• Input 1 20mA
• Input 2 0mA
• Input 2 20mA
Process Input
• Flow Units
• Full Scale
• Master TC
L.F. Cutoff
• L.F. Cutoff
• Cutoff on
Opt
• Cutoff off Opt
• VOS Min/Max Units
• Min VOS
• Max VOS
Current Output
Current Output
• Function I
• Direction I
• Range I
• I 0%
• I 100%
• Limit
• Calibration 4mA
Opt
• Calibration 20mA Opt
Pulse Output
• Function P Opt
• Direction P Opt
• Digital Output Opt
• Trip. Point 1 Opt
• Trip. Point 2 Opt
• Time Constant Opt
• Output Opt
• Pulserate Units Opt
• Pulserate Opt
• Units Pulse/Unit Opt
• Pulse/Unit Opt
• Pulsewidth Opt
Display
• Display Flow
• Function Totalizer
• Display Totalizer
• Volume Units
Opt
• Energy Units Opt
• VOS Units
• Analog Input
Opt
• Signal Gain
Local Display
• Language
• Cyclic Display
• Error Messages
• Date
• Text Volume
• Text Time
• Unit Volume
• Unit Time Display Formats
• Format Flow
Loc
• Format Heat Flow Opt, Loc
• Format Volume Loc
• Format Energy Opt, Loc
