TECHNICAL DATA
6
37
OPTIMASS 6000
www.krohne.com 07/2014 - 4001894003 - MA OPTIMASS 6000 R03 en
6.3 Measuring accuracy
Measuring error
The measuring error is obtained from the combined effects of accuracy and zero stability.
Reference conditions
6.4 Guidelines for maximum operating pressure
Notes:
• Ensure that the meter is used within its operating limits
• All hygienic process connections have a maximum operating rating of 10 barg
at 150°C / 145 psig at 302°F
X nominal flow rate [%]
Y measuring error [%]
Product Water
Temperature +20°C / +68°F
Operating pressure 1 barg / 14.5 psig
