TECHNICAL DATA
6
43
OPTIMASS 2000
www.krohne.com 10/2010 - 4000810002- MA OPTIMASS 2000 R02 en
8" - 1911 -
10" - - 2400
12" - - 2400
JIS 10K JIS 10K JIS 10K JIS 10K
100A 1332 - -
JIS 20K JIS 20K JIS 20K JIS 20K
100A 1332 - -
Dimension B [inches]
S100 S150 S250
PN16 PN16 PN16 PN16
DN100 50.5 - -
DN150 50.5 62.2 -
DN200 - 62.2 -
DN250 - - 77.2
DN300 - - 77.2
PN40 PN40 PN40 PN40
DN100 51.5 - -
DN150 52.6 64 -
DN200 - 65.5 -
DN250 - - 80.7
DN300 - - 82.3
PN63 PN63 PN63 PN63
DN100 53.2 - -
DN150 52.3 67 -
DN200 - 65 -
DN250 - - 84.8
DN300 - - 81.5
PN100 PN100 PN100 PN100
DN100 53.9 - -
DN150 55.5 66.6 -
DN200 - 68.3 -
DN250 - - 83.5
DN300 - - 85.9
PN160 PN160 PN160 PN160
DN100 54.3
DN150 56.5 68 -
DN200 68.9 -
DN250 83.9
DN300 - - 85.4
Dimension B [mm]
S100 S150 S250
