TECHNICAL DATA
6
33
OPTIMASS 2000
www.krohne.com 10/2010 - 4000810002- MA OPTIMASS 2000 R02 en
On site calibration
± 0.5 kg/m 3 / ±0.033 lbs/ft 3
Temperature Temperature Temperature Temperature
Accuracy ± 1°C / ±1.8°F
Operating conditions
Maximum flow rates Maximum flow rates Maximum flow rates Maximum flow rates
S100 420000 kg/h / 14698 lbs/min
S150 900000 kg/h / 33804 lbs/min
S250 2300000 kg/h / 84510 lbs/min
Custody transfer flow rates (mass) Custody transfer flow rates (mass) Custody transfer flow rates (mass) Custody transfer flow rates (mass)
S100 11000...220000 kg/h / 404...8083 lbs/min
S150 25000...500000 kg/h / 919...18371 lbs/min
S250 60000...1200000 kg/h / 2205...44092 lbs/min
Custody transfer flow rates (volume) Custody transfer flow rates (volume) Custody transfer flow rates (volume) Custody transfer flow rates (volume)
S100 11...220 m 3 /h / 1660...33210 bbl/day
S150 25...500 m 3 /h / 3774...75478 bbl/day
S250 60...1200 m 3 /h / 9057...181147 bbl/day
Assumes operating density 1000 kg/m 3 / 62.4 lb/ft 3
Ambient temperature Ambient temperature Ambient temperature Ambient temperature
Compact version with Aluminium
converter
-40...+60°C / -40…+140°F
Extended temperature range: 65°C / 149°F for some I/O options. For more
information contact manufacturer.
Compact version with Stainless Steel
converter
-40...+55°C / -40…+130°F
Remote versions -40...+65°C / -40…+149°F
Process temperature Process temperature Process temperature Process temperature
Flanged connection -45…+130°C / -49…+266°F
Hygienic connection (S100 only)
Nominal pressure at 20 Nominal pressure at 20 Nominal pressure at 20 Nominal pressure at 20°C / 68 C / 68 C / 68 C / 68°F F F F
Measuring tube (Duplex UNS S31803) Measuring tube (Duplex UNS S31803) Measuring tube (Duplex UNS S31803) Measuring tube (Duplex UNS S31803)
PED 97/23/EC -1…150 barg / -14.5…2175 psig
FM -1…140 barg / -14.5…2030 psig
CRN / ASME B31.3 -1…100 barg / -14.5…1450 psig
Measuring tube (Super Duplex UNS S32750) Measuring tube (Super Duplex UNS S32750) Measuring tube (Super Duplex UNS S32750) Measuring tube (Super Duplex UNS S32750)
PED 97/23/EC -1…180 barg / -14.5…2610 psig
FM -1…140 barg / -14.5…2030 psig
CRN / ASME B31.3 (pending) -1…130 barg / -14.5…1885 psig
Outer cylinder Outer cylinder Outer cylinder Outer cylinder
Non PED / CRN approved Typical burst pressure > 100 barg / 1450 psig
PED approved secondary containment -1...40 barg / -14.5...580 psig
-1...150 barg / -14.5...2175 psig (Duplex option)
Effect on sensor zero point caused by a shift in process temperature Effect on sensor zero point caused by a shift in process temperature Effect on sensor zero point caused by a shift in process temperature Effect on sensor zero point caused by a shift in process temperature
Stainless Steel 0.0004% per 1°C / 0.000022% per 1°F
