TECHNICAL DATA
6
41
OPTIMASS 2000
www.krohne.com 10/2010 - 4000810002- MA OPTIMASS 2000 R02 en
Measuring tube in Stainless Steel
Flange connections
Dimensions [mm]
S100 S150 S250
A 219 ±5 323 ±5 406 ±5
C1 (compact) 370 ±5 422 ±5 463 ±5
C2 (remote) 293 ±5 345 ±5 386 ±5
D 160
E 60
F 123.5
G 137
H 98.5
Dimensions [inches]
S100 S150 S250
A 8.6 ±0.2 12.7 ±0.2 16 ±0.2
C1 (compact) 14.6 ±0.2 16.6 ±0.2 18.2 ±0.2
C2 (remote) 11.5 ±0.2 13.6 ±0.2 15.2 ±0.2
D 6.3
E 2.4
F 4.9
G 5.4
H 3.9
Dimension B [mm]
S100 S150 S250
PN16 PN16 PN16 PN16
DN100 1284 - -
DN150 1284 1581 -
DN200 - 1581 -
DN250 - - 1960
DN300 - - 1960
PN40 PN40 PN40 PN40
DN100 1310 - -
DN150 1330 1621 -
DN200 - 1647 -
DN250 - - 2030
DN300 - - 2050
PN63 PN63 PN63 PN63
DN100 1336 - -
DN150 1370 1661 -
DN200 - 1691 -
