Temperature indication too high or too low
When reference measurements result in an incorrect temperature indication, three causes
come into question:
• Severe heat transfer caused by too short insertion length of thermowell: the compact sensor
indicates a temperature that is too low when it is above the ambient temperature and one that
is too high when it is below the ambient temperature.
• Severe heat transfer via the process connection, the pipeline or the tank wall due to a lack of
insulation.
• Incorrect thermowell dimensions (diameter, wall thickness).
To keep the heat transfer to a minimum, either increase the insertion length of the compact
sensor or improve the insulation of the measuring point.
Damage to the thermowell and penetrating liquid
If the thermowell is not sufficiently resistant to chemically aggressive media, corrosion may
occur and the measured medium may penetrate. In case of doubt, choose a thermowell made of
the same material as the pipe or tank in which the medium is located.
Breaks or tears
It is possible for breaks or tears to occur due to the force of the media flowing against the
thermowell. It is also possible for vibrations in the resonance range to damage or destroy the
thermowell. Superimposition of the two causes or a combination of insufficient mechanical and
chemical resistance is also possible. The following are starting points for troubleshooting:
• Selection of a thermowell with different dimensions
• Change in neck tube length at critical head resonances
• Selection of a different installation site
