ALTOFLUX IFM x080 K-EEx and ALTOFLUX IFM x080 K / i-EEx

Primary head
The IFS 5000-EEx primary head of the IFM 5080 K/…-EEx compact flowmeter contains two
field coils above and below the measuring tube and two electrodes inside the ceramics
measuring tube on both sides. The field coils have type of protection increased safety "e"
according to EN 50019 and encapsulation "m" according to EN 50028. The electrodes are
provided with type of protection intrinsic safety "ib" according to EN 50020.

The primary head is available in meter sizes DN2.5 up to DN100. The IFC 090/…-EEx signal
converter (described in Sect. 1.4-1.5) is mounted on top of the primary head by four recessed
head screws of size M6 with internal hexagonal socket set.

Note:

The intrinsically safe electrode circuits of the IFM 5080K/…-EEx compact flowmeter are

only internal circuits and not accessible for the customer.

Data plates of ALTOFLUX IFM 5080 K

IFM 5080 K … EEx

IFM 5080 K / i … EEx

SEE CERTIFICATE FOR MAXIMUM TEMPERATURES.

DO NOT OPEN ENCLOSURE WHEN ENERGIZED !

MAX. SHORT-CIRCUIT CURRENT OF MAINS: A

10VA Um=253V

ENCLOSURE: T6 %%242 20 MIN.; T5 %%242 11 MIN.

WAITING TIME BEFORE OPENING OF THE FLAMEPROOF

INTRINSICALLY SAFE CIRCUITS: ELECTRODE CIRCUIT,

ONLY INTERNAL CONNECTIONS.

AMBIENT TEMPERATURE: -20...+60%%DC.

II 2GD EEx dme [ib] IIC T6...T3

IFM 5080 K-EEx

SPACE FOR ADDITIONAL DATA

Kerkeplaat 12

KEMA 01 ATEX 2262 X

3313 LC Dordrecht
The Netherlands

48-63Hz

POWER

SERIAL NO.

Vac

Altometer

TYPE

T80...165%%DC

+30%

Vdc

8 W

-25%

IP65/67

PRODUCTION

2002

YEAR OF

0344

WAITING TIME BEFORE OPENING OF THE FLAMEPROOF

DO NOT OPEN ENCLOSURE WHEN ENERGIZED !

MAX. SHORT-CIRCUIT CURRENT OF MAINS: A

Electrode circuit: only internal connections

Active output

Co=127nF; Lo=4mH;

Uo=23.5V; Io=98mA; Po=0.6W

Passive output

Ci=5nF; Li=0; EEx ia IIC

Ui=30V; Ii=300mA; Pi=4.2W

Ci=5nF; Li=0; EEx ia IIC

Ui=30V; Ii=250mA; Pi=1.0W

Passive output

INTRINSICALLY SAFE CIRCUITS

Term. 100...230Vac,+10%/-15%

48-63Hz,8W,Um=253V

24Vdc,+30%/-25%,10W,Um=253V

Term. 24Vac,+10%/-15%,48-63Hz,10W

ENCLOSURE: T6 %%242 20 MIN.; T5 %%242 11 MIN.

AMBIENT TEMPERATURE: -20...+60%%DC.

SEE CERTIFICATE FOR MAXIMUM TEMPERATURES.

II 2GD EEx dme [ib] [ia] IIC T6...T3

IFM 5080 K/i-EEx

Kerkeplaat 12

KEMA 01 ATEX 2262 X

3313 LC Dordrecht
The Netherlands

I /I

I+/I

B1+/B1

D/D

B2/B2

B1/B1

%%uTerm.

L, N

1L ,0L
