IFC
010
13
4.2 Table of settable functions
Function
Text
Description and settings
1.00
OPERATION Operations
menu
1.01
FULL SCALE
Full-scale range for flowrate Q
100%
Select unit
• m
3
/hr • Liter/Sec • US.Gal/min
• user unit, factory set is “Liter/hr” or “US MGal/day” (see Fct. 3.05)
Press
→ key to transfer to number setting.
Setting ranges
The ranges are dependent on the meter size (DN) and the flow
velocity (v): Q
min
= DN
2
x v
min
Q
max
= DN
2
x v
max
Nom. dia./meter size v
min
= 0,3 m/s v
max
= 12 m/s
(1 ft/s) (40 ft/s)
• DN 2.5–1000 / 1/10”–40”: 0.0053 – 33 900 m
3
/hr
0.0237 – 152 000 US.Gal/min
→ VALUE P
Pulse value (Fct. 1.06 “VALUE P”) has been changed.
1.02
TIMECONST. Time
constant
Select:
• ALL
(applies to display and all outputs)
• ONLY I+S
(only display, current and status outputs)
Range: • 0.2 – 99.9 Sec
1.03
L.F.CUTOFF
Low-flow
cutoff (SMU)
• OFF (fixed trip points: ON = 0.1% / OFF = 0.2%
for 100 and 1000 Hz, see Fct. 1.06, 1% or 2%)
• PERCENT (variable values) ON OFF
1 – 19% 2 – 20%
Note:
Cutoff “off” value must be greater than cutoff “on” value.
Press
↵ key to return to Fct. 1.03 L.F. CUTOFF.
1.04
DISPLAY
Display
functions
→ DISP.FLOW
Select flow display
• NO DISP.
• user unit, factory set is “Liter/hr” or “US MGal/day (see Fct. 3.05)
• m
3
/hr
• PERCENT
• Liter/Sec
• BARGRAPH (value and bargraph display in %)
• US.Gal/min
→ DISP.TOTAL.
Select totalizer display
• NO DISP. (totalizer switched on but not displayed)
• OFF (totalizer switched off)
• +TOTAL. • –TOTAL. • +/–TOTAL. • SUM (
Σ)
• ALL (displaysingle counts or all)
• m
3
• Liter • US.Gal
• user unit, factory set is “Liter” or “US MGal” (see Fct. 3.05).
Press
→ key to transfer to format setting.
Format setting
• Auto (exponent notation)
• # . #######
• ##### . ###
• ## . ######
• ###### . ##
• ### . #####
• ####### . #
• #### . ####
• ########
→ DISP.MSG.
Additional messages required in measuring mode?
• NO
• YES (cyclic change with displays of measured values)
Press
↵ key to return to Fct. 1.04 DISPLAY.
π
4
π
4
