3 Product description
3.1 Configuration
The scope of delivery encompasses:
l
SU 501 Ex signal conditioning instrument
l
Documentation
- this operating instructions manual
SU 501 Ex consists of the following components:
l
SU 501 Ex signal conditioning instrument
5 6 7 8
9 10 12 13 14
TEST
on
2
1
3
Fig. 1: SU 501 Ex
1 Ex separating chamber with Ex version
2 Socket
3 Transparent cover
3.2 Principle of operation
SU 501 Ex is a single signal conditioning instrument for
processing of vibrating level switches.
SU 501 Ex signal conditioning instrument can power connec-
ted instruments and process their measuring signals.
You can find detailed information on the power supply in the
"Technical data" in the "Supplement".
