DEVICE DESCRIPTION
2
9
OPTITEMP TR/TC 100
www.krohne.com 10/2009 - 4000630002 - MA OPTITEMP TR/TC 100 R02 en
Device description
2.1 Scope of delivery
Delivery includes the measuring insert itself and the appropriate documentation.
2.2 Device description
The actual temperature sensor, either a Pt100 RTD or a thermocouple, is located in the
replaceable measuring insert. It is inserted through the open head into the thermometer fitting
and attached with two spring loaded M4 screws . The design, dimensions and other construction
features of the measuring inserts are standardized:
Standards for measuring inserts
• DIN 43735-1: electrical temperature sensor for resistance thermometers and
thermocouples, Part 1: removable measuring inserts.
INFORMATION!
Inspect the cartons carefully for damage or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
INFORMATION!
Check the packing list to check if you received completely all that you ordered.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
Type of measuring insert Included documentation
Measuring insert with terminal block Manual for measuring inserts
Measuring insert without terminal block Manual for measuring inserts
Measuring insert with transmitter Manual for measuring inserts, transmitter manual
Ex measuring insert with Ex transmitter Manual for measuring inserts, Ex-manual for
measuring inserts, transmitter manual, Ex-manual
for transmitter
CAUTION!
The sheaths on the measuring insert are made of stainless steel or Inconel 600
® . Prior to
starting up the measuring inserts, observe the specifications in the corrosion tables (they are
accessible to the public and can be found, for example, in the Internet).
