Supplementary Installation and Operating Instructions IFC 300 HART
HC275, FC375, AMS, PDM, FDT DTM
Attachment C
IFC 300 HART Menu Tree PDM
Menu Bar
File Device View Options Help
Communication Path
-----------------------------------
Load To Device
Load To PG/PC
-----------------------------------
Set Address
-----------------------------------
Test
Reset
Calibration
-----------------------------------
Parameter Protection
-----------------------------------
HART
Test
• simuation. current/frequency A
Opt, Cust
• simuation current/frequency B Opt, Cust
• simuation current C Opt, Cust
• simuation frequency D Opt, Cust
HART
preambles
• request preambles
Rd
• response preambles
Reset
•
•
•
Calibration
• automatic zero calibration
Cust
• D/A trim Cust
• apply values Cust
dynamic variables settings
• PV is
Rd
• SV is
• TV is
• 4V is
2,3
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Cust Custody Lock protected
Loc Local PDM, affects only PDM views
