Supplementary Installation and Operating Instructions IFC 300 HART
HC275, FC375, AMS, PDM, FDT DTM
Attachment B
Configure
Compare
Clear Offline
-----------------------------------
Status/Conditions
Process Variables
Scan Device
-----------------------------------
Calibration Management
Diagnostics and Test
Calibrate
Reset
-----------------------------------
Rename
Unassign
Assign / Replace
-----------------------------------
Audit Trail
Record Manual Event
Drawings / Notes ...
Help ...
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Cust Custody Lock protected
Loc Local AMS, affects only AMS views
IFC 300 HART Menu Tree AMS
quick setup
device:
• language
• tag
pulse output D:
• pulse value unit
Opt, Cust
• value p. pulse D Opt, Cust
current output A/C:
• unit A/C
Cust
• range A/C max Cust
• range A/C min Cust
• time constant A/C Cust
• lfc threshold A/C Cust
• lfc hysteresis A/C Cust
5
KROHNE IFC 300 HA 45e30102 (1/5)
06/05
input calibration
• zero set Cust
• size Cust
• GK selection Cust
• GK / GKH Opt, Cust
• GKL Opt, Cust
• coil resist. Rsp Cust
• density Cust
sensor
volume flow sensor limits:
• upper sensor limit
Rd
• lower sensor limit Rd
• minimum span Rd
mass flow sensor limits:
...
flow speed sensor limits:
...
conductivity sensor limits:
...
coil temperature snsr limits:
...
• target conductivity Cust
• EF electrode factor Cust
• num. of electrodes
• field frequency
Cust
• select settling Cust
• settling time Opt, Cust
• line frequency Cust
input filter
• limitation max Cust
• limitation min Cust
• flow direction Cust
• time constant
• pulse filter
Cust
• pulse width Cust
• pulse limitation Cust
• noise filter Cust
• noise level Cust
• noise suppression Opt, Cust
• lfc threshold Cust
• lfc hysteresis Cust
self test / info
self test:
• empty pipe
Cust
• limit empty pipe Opt, Cust
• full pipe Opt, Cust
• limit full pipe Opt, Cust
• linearity Cust
• gain Cust
• coil current Cust
self test:
• flow profile
Cust
• limit flow profile Opt, Cust
• electrode noise Cust
• limit elect. noise Opt, Cust
• settling of field Cust
information:
• liner
• electrode material
4
5
