Supplementary Installation and Operating Instructions IFC 300 HART
HC275, FC375, AMS, PDM, FDT DTM
1 dynamic
variables
2 quick setup
3 test
4 setup
IFC 300 HART Menu Tree HC275 / FC375
1 process input
2 I/O
3 communication
4 device
1
1
1 HART
1 address
2 D/A trim
Cust
3 apply values Cust
4 message
5 descriptor
6 device information
7 dynamic variables
settings
8 preambles
9 master reset
1 PV is Rd
2 SV is
3 TV is
4 4V is
1 tag
2 C number
Rd
1 list errors
2 reset errors
2
1 manufacturer Rd
2 model Rd
3 device ID Rd
3 tag
4 date
5 write protect
Rd
6 final assembly no.
7 sensor serial no.
8 revision nos.
1 universal rev. Rd
2 device rev. Rd
3 software rev. Rd
4 hardware rev. Rd
1 request preams Rd
2 response preams
1 device info
2 display
3 1. meas. page
4 2. meas. page
3 special functions
4 units (device)
5 units (HART)
6 formats (HART)
7 circuit board info
1 volume flow Cust
2 mass flow Cust
3 flow speed
4 conductivity
5 temperature
6 volume
Cust
7 mass Cust
8 density Cust
1 volume flow
2 mass flow
3 flow speed
4 conductivity
5 temperature
6 counter 1
7 counter 2
1 language
2 default display
Cust
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Cust Custody Lock protected
Loc Local HC275/FC375,
affects only HC275/FC375 views
KROHNE IFC 300 HA 45e30102 (3/3)
06/05
1 function Cust
2 measurem. 1. line Cust
3 range min Cust
4 range max Cust
5 limitation min
6 limitation max
7 lfc threshold
8 lfc hystereis
9 time constant
10 format 1. line
11 measurem. 2. line
Cust
12 format 2. line Cust
13 measurem. 3. line Cust
14 format 3. line Cust
