RTW 300W 101212
3
Output Hold-up Time
30 mSec typ. (25 mSec typ. for 5V
and 15V models), 20 mSec min.
100V a-c
40 mSec typ. (30 mSec typ. for 5V
and 15V models), 25 mSec min.
240V a-c
Overvoltage Protection
When the Power Supply goes into an overvoltage condition, the output is cut OFF. To restart
(reset) the unit, it is necessary to remove, then reconnect the a-c input power after about 30
seconds, or to open and then reclose the RC terminals.
Remote Control ON/OFF:
"High", 2.4V to 24V (or open), unit OFF- Fan Off ; "Low", 0.0V to 0.4V (or closed), unit ON.
When remote ON/OFF is not in use, ±RC pins of connector CN2 or CN3 should be shorted
(use connector supplied) for unit to operate.
Operating Temperature:
-10 to 71°C (see figures 2 and 3)
Startup Temperature
-20 to -10°C (see Figure 2)
Storage Temperature:
-30°C to +75°C
Humidity:
10% to 95% relative humidity, noncondensing, Wet Bulb tem-
perature
operating and non-operating
Vibration:
5-10 Hz., 10mm amplitude,
10-200 Hz., acceleration 64.3ft./s
2
( 19.6m/s
2
) (2g)
non-operating, 1 hr. on each
of 3 axes, sweep time 10 min-
utes
Shock: Acceleration:
1929.1ft./s
2
(588m/s
2
) (60g),
Pulse Duration: 11ms ± 5 mSec
(non-operating, 1/2 sine
pulse, three shocks on each
axis)
Withstanding voltage : (at 15-35°C
ambient, 10-85% relative humidity)
2000Va-c for 1 minute. Cutout current is 10mA
Between input and ground
500Va-c for 1 minute. Cutout current is 40mA
Between output and ground
3000Va-c for 1 minute. Cutout current is 10mA
Between input and output
Insulation Resistance: (at 15-35°C
ambient, 10-85% relative humidity)
Between output and ground, input and ground, and input and output, 100 Megohms minimum
(500Vdc)
Safety:
UL60950-1 First Ed., CSA Electrical Bulletin 22.2 No.60950-1, and TÜV Rheinland
EN60950-1:2001, Assistance for Den-AN
(2)
(ambient temp.50°C max.). RTW 300W units are
CE marked per the Low Voltage Directive (LVD), 73/23/EEC and 93/68/EEC. The standards do
not apply with DC input operation
EMI Conducted:
Designed to meet FCC Class B, VCCI-Class B, EN55011-B, EN55022-B
EMI Radiated:
Designed to meet FCC Class B, VCCI-Class B, EN55011-B, EN55022-B
ESD immunity:
Designed to meet EN61000-4-2, level 4
normal operation
Electrical fast transient burst:
EN61000-4-4 level 3
normal operation
Surge withstand:
EN61000-4-5, level 4
no damage
Power Frequency Magnetic Field:
EN61000-4-8, level 4
normal operation
Radiated susceptibility:
EN61000-4-3 level 3
normal operation
Conducted susceptibility:
EN61000-4-6 level 3
normal operation
Voltage dips interruptions and
variations
EN61000-4-11
normal operation
Input harmonics current:
Designed to meet EN61000-3-2
Dimensions:
4.72 in. (120 mm) H x 1.57 in. (40 mm) W x 9.84 in. (250 mm) L
Mounting:
Four No. M4 tapped holes on the sides and the bottom
Maximum Screw Penetration:
0.24 in. (6 mm)
Cooling: Convection
Frame Material
Aluminum
Weight
2.87 lbs. (1.3Kg) maximum
(2) Meets the creepage and clearance requirement of Den-An Appendix 8 (100V a-c only).
TABLE 2. POWER SUPPLY RATINGS AND SPECIFICATIONS (CONTINUED)
SPECIFICATION
DESCRIPTION
