D. MODIFY TABLE A-2 TO ADD BIT 6 = PROTECTION ERROR
E. ADD THE FOLLOWING TO APPENDIX B
B.4A CALibrate:CPRotect COMMAND
CAL:CPR
Syntax: Short Form: CAL:CPR {MIN | MAX}
Long Form: CALibrate:CPRotect {MIN | MAX}
Description: Selects Current Protection limit calibration, only effective with power supply in Calibrate status. CAL:CPR
MAX selects maximum positive current protection limit calibration. CAL:CPR MIN selects maximum negative cur-
rent protection limit calibration. Related Commands: CAL:STAT, CAL:ZERO, CAL:DATA, CAL:SAVE.
F. MODIFY TABLE B-5 TO ADD BIT 14 = PROTECTION ERROR
TABLE A-2. STANDARD EVENT STATUS ENABLE REGISTER AND STANDARD
EVENT STATUS REGISTER BITS
CONDITION NU PE CME EXE DDE QUE NU OPC
BIT 7 6 5 4 3 2 1 0
VALUE 128 64 32 16 8 4 2 1
NU (Not Used)
PE Protection Error
CME Command Error
EXE Execution Error
DDE Device Dependent Error
QUE Query Error
OPC Operation Complete
TABLE B-5. QUESTIONABLE EVENT REGISTER, QUESTIONABLE CONDITION REGISTER
AND QUESTIONABLE CONDITION ENABLE REGISTER BITS
CONDITION NU PE CE VE NU CM VM
BIT 15 14 13 12 11 - 2 1 0
VALUE 32,768 16,359 8192 4096 2048 - 4 2 1
PE PROTECTION ERROR
CE CURRENT ERROR
VE VOLTAGE ERROR
CM CURRENT MODE
VM VOLTAGE MODE
NU
NOT USED
