Operation
F232201 16
* Design U6 and greater models
W6 Wash 6 (extra low agitation)
W7 Wash 7 (no agitation, drain 1 open, no
refill)
WD Wash drain step – shortest drain time. Use
only if not followed by a spin step. Drain 1
open, no rotation.
WF Warm flush
WH Warm fill to high level
WM Warm fill to medium level
WL Warm fill to low level
WO Warm fill to overflow level
WR Warm rinse
• Left dot–poor balance condition
• Second dot from left–door lock switch
• Third dot from left–Program Mode
• Fourth dot from left–high level reached
• Fifth dot from left–medium level reached
• Right dot–low level reached
EXISTS Cycle already in memory
EDIT? Do you want to edit the cycle?
TEMP Over-temperature-limit condition
OVERHT Open or shorted temperature input circuit
or temperature out of computer’s allowable
limits
WATER Water in washer-extractor at end of cycle
°FAR Temperature in degrees Fahrenheit
°CEN Temperature in degrees Centigrade
MANUAL Manual Mode enabled
NO MAN Manual Mode disabled
1DRAIN One drain capability selected
2DRAIN Second independent drain enabled (via
Auxiliary 2 output–precludes control of
recirculation pump via Auxiliary 2, if
selected). This should not be confused with
the “dual drain” option.
ADV Advance (skip steps) feature enabled
Display Interpretations
Table 1
NO ADV Advance feature disabled
WET CL Wet clean function for Auxiliary 1 output
(1/2 wash speed) and Auxiliary 2 output
(recirculation pump) enabled (see
“2DRAIN.”)
NO WCL Wet clean function for Auxiliary 1 and 2
disabled (Auxiliary 1 and 2 are timed
outputs.)
S BAL “Short” balance routine–active only if
inverter drive load balance sensing is
utilized.
L BAL “Long” balance routine–active only if AC
inverter drive load balance sensing is
utilized.
DRTEMP Temperature is above 160°F in drain to
reuse tank A or B step.
BAL DR*
(flashing at
the end of
cycle) Cycle aborted due to extreme out-of-
balance condition or door is unstable.
Display Interpretations
Table 1
