42 Digital Output
1. Press “M**** ”.
*
Type in the desired page number(4 digits) after “M”.
2. After “AM”, the data will be displayed.
Output Content
A. Measuring Parameter
WTH: Flow Rate; Temperature; Humidity
WT: Flow Rate; Temperature
VTH: Velocity; Temperature; Humidity
VT: Velocity; Temperature
PRS: Pressure
B. Measuring Mode
000: Calculation Mode
001: Flow Rate Mode
C. Sampling Time
D. Number of Data
E. Calculation Mode
AVG: Average
INS: Instantaneous
In the case of Flow Rate Mode, the number of points is indicated.
F. Width
G. Height
H. Diameter
I. Units of Duct Size
1. Press “B ”
2. After “AB”, the data will be displayed.
Output Content
*
Same as shown above.
A B
C D E F G H
I
Example
Example
Example
■
Pressure is only
available on
MODEL6501-B0
/-C0.
