37
Press to select the contents of the
Print Out.
Use to select from items 1 to 3
and press to print out.
Please refer to the printing example shown below.
1. RESULT… Conditions and Calculation Results
2. DATA…… Conditions and Stored Data
3. ALL……… Conditions, Calculation Results and Stored Data
Example of Print Out
Measurement
Data
(DATA)
PAGE SET
PAGE:001
MODE:CALCULATION(A)
DATE:2001/05/19
TIME:11:32:26
DATA:010
SAMPLING TIME:001
START:001 END:010
MAX 0.75 m/s
AVG 0.40 m/s
MIN 0.05 m/s
MAX 25.8 ﾟ C
AVG 25.6 ﾟ C
MIN 25.4 ﾟ C
MAX 59.1 %RH
AVG 58.2 %RH
MIN 57.5 %RH
DT 16.8 ﾟ C
DI 73.4
NUM. m/s ﾟ C %RH
001 0.05 25.8 57.5
002 0.06 25.8 57.6
003 0.48 25.6 57.7
004 0.48 25.6 57.8
005 0.56 25.6 58.0
006 0.48 25.6 58.3
007 0.39 25.5 58.5
008 0.75 25.5 58.7
009 0.27 25.4 58.8
010 0.46 25.4 59.1
PAGE SET
PAGE:011
MODE:FLOW RATE
DATE:2001/06/21
TIME:16:23:08
DATA:003
DIV.:005
SAMPLING TIME:001
START:001 END:005
SHAPE W 200 H 300mm
MAX 32194 m3/h
AVG 16871 m3/h
MIN 5446 m3/h
MAX 25.9 ﾟ C
AVG 25.9 ﾟ C
MIN 25.8 ﾟ C
MAX 72.2 %RH
AVG 71.2 %RH
MIN 69.7 %RH
MAX 1.49 m/s
AVG 0.78 m/s
MIN 0.25 m/s
NUM. m3/h ﾟ C %RH
001 20596 25.8 69.7
002 19906 25.9 72.2
003 6214 25.9 71.3
004 5446 25.9 71.4
005 32194 25.9 71.4
Conditions
(Always
printed out)
Calculation
Results
(RESULT)
■ Humidity is only available on MODEL6531/6533.
■ Air temperature is only available on MODEL6531/6541/6542/6533/6543/6561.
■ Pressure is only available on MODE 6051-B0/6051-C0
Aaaaa PRINT OUTPUT
1 .RESULT
2.DATA
3.ALL
