Use
to select
“2. SAMPLING(n)”and press
.
Use
to select No. TRIAL (1 to
9999) and press
.
Use
to select
“3. MEAS. POINT” and press
.
Use to select the number of
MEAS. POINT (1 to 2000) and press
.
Use
to select
“4. DATA STORAGE?” and press
.
Use
to select YES or NO and
press
.
Use
to select
“5. DUCT ENTRY NO.” and press
.
*
If you select an empty ENTRY NO., you
cannot start the Flow Rate measurement.
The duct type settings screen will be
displayed. Here you can input the
dimensions of the duct.
*
Refer to “Duct Shape/Size Input” on P.16 for
details.
Use
to select
“6. SET TO START” and press
.
If you press
before saving the settings you will return back to the
Main Menu and any setting changes you made will not be saved.
