18 Normal Measurement NORMAL MODE
§ 3 Normal Measurement NORMAL MODE
This is the mode that you will be in, when you first turn on the
instrument. In this mode you cannot save any data. The display is
updated every 1 second.
To move to NORMAL Mode from
another measuring mode, press .
Select “1. NORMAL” and press .
Selecting the Measuring Parameters
The measurement parameters can be selected in Normal Mode as
described below.
While in Normal Mode as shown left,
the measured item can be changed by
pressing . The item changes in the
following sequence: Pressure→Air
Rate→Air Velocity
Pressure measurement is a feature for
MODEL 6501-B0/6501-C0.
This screen is displayed on MODEL
6501-B0/-C0, which has a built-in
pressure sensor.
The selected duct type will be
displayed at the lower left of the
screen.
To select the duct type, use
while pressing .
If you have not selected a duct type or your selected
duct type (number) is not available, the instrument will
not give you the flow rate reading. Make sure the duct
type is properly registered and selected. See “Getting
Started Duct Shape/Size Input” on P.16 for details. '12/04/12 a 16:24:37 ~
TC
C 1
D
CC 15
W CCC -
H CCC -
------a
24.9e
63.7g
'12/04/12 a 16:24:37 ~
TC
C 1
D
CCC 3
C1050
6037a
24.9e
63.7g
'12/04/12 a 16:24:37 ~
0.31h
'12/04/12 a 15:40:23 ~
TC
C 1 0.87f
25.3e
64.1g
MENU aa 1.NORMAL
aaaaaa 2.DUCT a TYPE
aaaaaa 3.CALCULATION
aaaaaa 4.FLOW a RATE
aaaaaa 5.DATA a OUTPUT
aaaaaa 6.DATA a CLEAR
aaaaaa 7.UTILITY
aaaaaa 8.PRESSURE a ZERO
Duct type
■ Humidity is only
available on
MODEL6531/6533.
■ Air temperature is
only available on
MODEL6531/6541
/6542/6533/6543/
6561
■ Pressure is only
available on
MODEL6501-B0
/-C0.
