3. Display Description and Operation Procedure 15
3.5 MODE
Tap [MODE] to display the mode selection window (Authentication required).
*User needs to have authorization to change
measurement mode.
Choose a mode from the below selection and tap it;
“SINGLE”, “CONTINUOUS”, “INTERVAL”,
“REPEAT”, “STATS” or “STANDARD”.
Note that the instrument is capable of 180 hours of
continuous operation in every measurement mode.
Mode Description
[SINGLE MODE]
Perform a measurement once within the pre-set time frame.
Example: If the setting is as follows in “CONFIG” menu (Refer to 3.7.1 SINGLE):
INTERVAL : N/A
SAMPLE T. : 00:00:15
CYCLES : N/A
A 15 second sampling is performed.
Measurement Flow
* Delay Time: Set Delay Time in START DELAY window referring to 3.10.3 OPTION.
Sampling Time
(15sec)
Start
Measurement
Finish
Measurement
Wait Time
Pump ON
Delay Time
10 sec
Wait Time
