Instruction Sheet
Rugged TROLL
®
200 Cable
Overview
Rugged TROLL 200 cable connects a Rugged TROLL 200 or Rugged BaroTROLL
Instrument directly to a controller or logger for communications. Rugged TROLL 200
cable is non-vented and is available in the following options.
l
Top-of-Well Cable Connector and RS485 Modbus wiring
l
Stripped-and-Tinned termination and RS485 Modbus wiring
l
Stripped-and-Tinned and SDI-12 wiring
The durable fitting on the cable connects to the probe body. The Top-of-Well Connector
fits with a Rugged TROLL Communication Device and allows connection to a
computer. Stripped-and-Tinned versions connect to a PLC or logger and provide
external power to the instrument.
Cable Specifications
Jacket options TPU (Thermoplastic Polyurethane)
Conductors 4 conductors, 24 AWG, polypropylene insulation
Diameter Cable, 5.1 mm (0.200 in.); Connector, 26.1 mm (1.03 in.)
Minimum bend radius 5x cable diameter 25.4 mm (1.0 in.)
Break strength 150 lbs (68 kg)
SDI-12 Cable Lengths
l
5.0 m (16.5 ft)
l
15.2 m (50 ft)
l
30.5 m (100 ft)
l
61.0 m (200 ft)*
*All cables 61 m (200 ft) and longer are supplied with spools.
