Diagnostics tab – Allied Telesis AT-2916SX User Manual
Page 31
Advanced Control Suite User’s Guide
31
test uses TCP/IP, as shown in Figure 6.
Figure 6. Network Test Tab
Diagnostics Tab
On the Diagnostics tab you can perform diagnostic tests on Allied Telesis
network adapters. You use this function to test the physical components of
the adapter, as shown in Figure 7 on page 31.
Note
The network connection is temporarily lost when the diagnostic tests
are running.
Figure 7. Diagnostics Tab
The Diagnostics tab contains the following fields:
