Chapter 2: Broadcom Advanced Control Suite 2 (BACS 2) Applications
30
ˆ Wake Up Capabilities. The Wake Up Capabilities property enables
the network adapter to wake up from a low-power mode when it
receives a network wake-up frame. Two types of wake-up frames are
possible: Magic Packet and Wake Up Frame.
Note
This parameter is available only for copper devices and is not
displayed for the AT-29xxSX Series adapters.
– Both (default). Selects both Magic Packet and Wake Up Frame as
wake-up frames.
– Magic Packet. Selects Magic Packet as the wake-up frame.
– None. Selects no wake-up frame.
– Wake Up Frame. Selects Wake Up Frame as the wake-up frame
and allows the network adapter to wake the system when an event
such as a ping or an Address Resolution Protocol (ARP) request is
received.
ˆ WOL Speed. The WOL Speed property sets the speed at which the
network adapter connects to the network while the network adapter is
in Wake on LAN mode. By default, the WOL Speed property is set to
Auto.
Note
This parameter is available only for copper devices and is not
displayed for the AT-29xxSX Series adapters.
– 10 Mb. Sets the speed to 10 Mbit/s. This is the network speed
when the system is in a standby mode awaiting a wake-up frame.
– 100 Mb. Sets the speed to 100 Mbit/s.
– Auto (default). Sets the speed for optimum network connection.
Network Test
Tab
In the Network Test tab, you can verify IP network connectivity. This test
verifies if the driver is installed correctly and tests connectivity to a
gateway or other specified IP address on the same subnet. The Network
