Advanced Control Suite User’s Guide
23
Configuring the BACS 2 Application
Start the BACS application and then click the tab on Broadcom
Advanced Control Suite 2 that provides the information of interest or
access to the tests, diagnostics, analyses, and configuration functions you
want to perform. Or, on the Tools menu, click Create a Team to start the
BASP application. Select from the following tabs:
ˆ “Vital Sign Tab” on page 23
ˆ “Resources Tab” on page 25
ˆ “Hardware Tab” on page 26
ˆ “Advanced Tab” on page 27
ˆ “Network Test Tab” on page 30
ˆ “Diagnostics Tab” on page 31
ˆ “Statistics Tab” on page 32
ˆ “BASP Statistics Tab” on page 35
Vital Sign Tab
The Vital Sign tab contains information about the adapter and other
network adapters that are installed, the link status of the network, and
network connectivity. To view this information for any installed network
adapter, click the name of the device, as shown in Figure 2 on page 24.
Note
Information about network adapters made by other vendors is less
comprehensive than the information provided about the Allied
Telesis AT-29xxSX series Gigabit Ethernet adapters or other
Broadcom-based adapters.
