BASIC MEASUREMENT
7
Resistance
Measurement item: 2W resistance, 4W resistance
1. Connect the
test leads
2W
resistance 4W
resistance
2. Press the
measurement
key
Press the measurement keys on the front panel. The
measurement result will appear on the display.
2W resistance 4W resistance
x 2 (twice)
Selected range Unit Refresh
rate
Automatic
ranging
2W or 4W
Manual ranging To select the measurement range
manually, press the Up/Down
keys.
For further details, see the Resistance section, Basic Measurement chapter in
the user manual
