GDM-8200A Series Quick User Guide
4
I
NTRODUCTION
The GDM-8200A series quick start guide is intended for users who are not
familiar with the instrument and need a tutorial for quickly accessing its major
functionalities. For more details such as parameters, remote control
commands, optional scanner, digital I/O, and specifications, refer to the user
manual.
This manual consists of the following chapters. Power up the instrument
according to the “Powering up” chapter, and then pick up the relevant chapter
according to your needs.

Powering up

Basic (measurement)

Voltage/Current

Resistance

Diode/Continuity/Frequency/Period/Temperature

Advanced (measurement)

dBm/dB/Max/Min/Relative/Dual display

Measurement combinations
Front panel
overview
