ARB
ARB – Enter Points
Example: ARB Ramp, 10 kHz, 1Vpp, 2 points.
Output
50
W
MAIN
1. Press FUNC>select the ARB wave
2. Press FREQ>1>0>kHz
3. Press AMPL>1>Vpp
4. Press Point>0>Enter
5. Press Value>5>1>1>Enter. (+511 amplitude)
6. Press Point>1>Enter
7. Press Value>+/->5>1>1>Enter. (-511
amplitude)
8. Press OUTPUT
Modulation
AM (2100 series only)
Example: AM modulation. 100Hz modulating square wave. 1 Vpp,
1kHz Sine wave carrier. 70% modulation depth. Internal source
signal.
Output
50 W
MAIN
1. Press FUNC>select the sine wave
2. Press FREQ>1>kHz
3. Press AMPL>1>Vpp
4. Press AM
5. Press Shift>INT/EXT>select INT source
6. Press Shift>Shape>select the square wave
7. Press Shift>Rate>1>0>0>Hz
8. Press Shift>DEP/DEV>7>0>%
9. Press Output
10. Press AM to deselect the AM function
