TABLE OF CONTENTS
5
Table of Contents
INTRODUCTION .......................................... 6
SPECIFICATIONS .......................................... 7
FRONT PANEL DESCRIPTION ..................... 9
CONNECTION METHOD ........................... 12
OPERATON METHOD ................................ 12
GDS-1000 Series User Manual
6
INTRODUCTION
The GRC-1201 is a special remote controller for the standard signal
generator GSG-family.
The main purpose of the GRC-1201 is to read the information stored in
the memory of GSG-family. Before the remote controller is used, such
information as the carrier frequency , output level, modulation factor,
and modulation mode must be written into the memory from the front
panel of the signal generator.
The values of the carrier frequency, output level, modulation factor, and
memory address can be changed by cursor keys and rotary knob.
