GDS-122 Rechargeable Battery Pack

Charging the Battery Pack

To avoid potential hazards, use this product only as specified.

Note

The Battery Pack needs to be fully charged for first-time
use. The battery pack begins to charge as soon as the
oscilloscope is connected to external AC power source. It
takes FOUR hours to fully charge the battery when
oscilloscope is turned OFF.

The battery pack stops charging under the following
conditions:

•

The battery pack is fully charged.

•

The battery pack temperature exceeds the operation
temperature specification in the below table.

Configuration

Typical charging time

Configuration

Battery pack charging in
oscilloscope with
oscilloscope turned OFF

4 hours

Battery Output for each one 7.4VDC, 3500mAh
Operating Temperature

°C~50°C, discharging and

charge

Specifications

Storage Temperature

-20

°C ~+60°C

Warranty

GWInstek warrants that the products that it manufactures and sells will be free from
defects in materials and workmanship for a period of three (3) months from the date of
shipment from authorized GWInstek representatives. If a product proves defective within
the replacement period, GWInstek will repair or provide a replacement as described in the
complete warranty statement.
EXCEPT AS PROVIDED IN THIS DOCUMENT OR IN THE APPLICABLE
WARRANTY STATEMENT, GWINSTEK MAKES NO WARRANTY OF ANY
KIND, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL GW INSTEK BE LIABLE FOR
INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES.
