Alto-Shaam ED2-48 - Manual (Page 26)

s E r V I c E
ED2 & EU2 Series Operation & Care Manual • 24
Part numbers and drawings are subject to change without notice . Part numbers and drawings are subject to change without notice .
5
6
4
3
2
1
8
7
3
9
I n n E r t o P a s s E M B l y ( E D 2 - 9 6 s h o w n )
6
5
4
3
2
1
11
10
9
8
7
s e r v i c e h i n g e k i t
ItEM DEscrIPtIon Qty ItEM DEscrIPtIon Qty
1 25° HInGE 2 7 MOUnTInG BLOCKS 2
2 GAS RAM PInS 2 8 HOLE PLUG 2
3 HInGE PIn 1 9 HInGE BOLT 2
4 PIn PLUG 6 10 LOCK WASHERS 2
5 LOWER GAS RAM PIn 1 11 GAS RAM HOLDER 2
6 MOUnTInG PIn 1
s e r v i c e h i n g e k i t
(
h g
- 2 8 1 6 0 )
MoDEl > ED2(sys)-48 ED2(sys)-72 ED2(sys)-96
ItEM DEscrIPtIon Part no. Qty Part no. Qty Part no. Qty
1 CAP, EnD, RH CP-27561 1 CP-27561 1 CP-27561 1
2 UPPER DOOR FILLER 1005031 1 1005032 1 1005034 1
3 SERVICE HInGE KIT (SEE InSET) HG-28160 1 HG-28160 1 HG-28160 1
4 LAMP RECEPTACLE 120V/208-240V RP-3952 6 RP-3952 10 RP-3952 14
LAMP RECEPTACLE 230V RP-3955 6 RP-3955 10 RP-3955 14
5 InnER TOP 1005017 1 1005018 1 1005024 2
6 OUTER TOP 5004030 1 5004031 1 5004034 1
7 CAP, EnD, LH CP-27560 1 CP-27560 1 CP-27560 1
8 CLAMP ASSEMBLY CM-26765 1 CM-26766 1 CM-26767 1
9* TOP TRACK TK-26752 1 TK-26754 1 TK-26756 1
10* STRUT 400n SU-26849 2 — — SU-26849 4
600n — — SU-26850 2 — —
* not shown
