s E r V I c E
ED2 & EU2 Series Operation & Care Manual • 20
Part numbers and drawings are subject to change without notice .
MoDEl >
ED2(sys)-48
ED2(sys)-72
ED2(sys)-96
ItEM
DEscrIPtIon
Part no.
Qty
Part no.
Qty
Part no.
Qty
1
DOOR GLASS, LH
DR-25422
1
DR-25422
1
DR-25422
1
2
DOOR GLASS, MIDDLE
DR-25423
1
DR-25423
1
DR-25423
2
3
DOOR GLASS, RH
—
—
DR-25424
1
DR-25424
1
4
DOOR TRACK, BOTTOM
TK-26751
1
TK-26753
1
TK-26755
1
5
UPRIGHT AnGLED SUPPORT
1004870
2
1004870
2
1004870
2
6
UPRIGHT WEDGE
BK-26025
2
BK-26025
2
BK-26025
2
7
GASKET, EnD GLASS
GS-22547
1
GS-22547
1
GS-22547
1
8
FROnT GLASS**
GL-25420
1
GL-25785
1
GL-25420
2
9
BRACKET, CUTTInG BOARD
BT-2342
2
BT-2342
2
BT-2342
4
*CUTTInG BOARD
4016
1
4017
1
4016
2
10
BRACKET, CUTTInG BOARD
11283
2
11283
2
11283
4
11
BULB
120V/208-240V; 100WATT
LP-33592
6
LP-33592
10
LP-33592
14
120V/208-240V; 65WATT
LP-34762
6
—
—
—
—
230V; 100WATT
LP-33783
6
LP-33783
10
LP-33783
14
12
EnD GLASS, CLEAR
GL-25762
2
GL-25762
2
GL-25762
2
13
EnD PAnEL, RH***
black
OP-26668
1
OP-26668
1
OP-26668
1
14
WELL, CABLE ASSEMBLY
5003844
1
5003845
1
5003846
1
15
FRAME, GLASS, WELL SUPPORT
1000647
2
1000647
2
1000647
2
16
InSULATIOn
In-22364
1
In-22364
1
In-22364
1
17
InSULATIOn
In-2003
1
In-2003
1
In-2003
1
18
CORD, 7" (2133mm)
120V/208-240V
CD-3291
1
CD-3557
1
CD-3557
1
CORD, 7" (2133mm)
230V
CD-33490
1
CD-33490
1
CD-33489
1
19
PLUG, nEMA L14-20P, 20A, 250V
PG-3337
1
—
1
—
1
PLUG, nEMA L14-30P, 30A, 250V
—
—
PG-3267
—
PG-3267
—
20
LEG MOUnT SPOT
5000712
4
5000712
4
5000712
6
21
REAR PAnEL TRIM***
black
OP-26660
1
OP-26664
1
OP-26666
1
22
RIGHT PAnEL TRIM***
black
OP-26661
1
OP-26661
1
OP-26661
1
23
FROnT PAnEL TRIM***
black
OP-26659
1
OP-26663
1
OP-26665
1
24
LEFT PAnEL TRIM***
black
OP-26662
1
OP-26662
1
OP-26662
1
25
LEGS, 4" (102mm)
adjustable
LG-2044
4
LG-2044
4
LG-2044
6
26
ACCESS PAnEL
1000620
1
1001264
1
1001469
1
27
WELL WRAPPER
1000613
1
1001255
1
1001468
1
28
EnD PAnEL, LH***
black
OP-26667
1
OP-26667
1
OP-26667
1
29
HAnDLE, GLASS
HD-27795
1
HD-27796
1
HD-27797
1
* nOT SHOWn
** See substitute parts section for self-service units (pg 22)
*** Black panels listed, See page 21 for Stainless Steel & Custom Color
f u l l a s s e m b l y • f r o n t v i e w
(Continued on next page)
