s E r V I c E
ED2 & EU2 Series Operation & Care Manual • 21
Part numbers and drawings are subject to change without notice .
MoDEl > ED2(sys)-48 ED2(sys)-72 ED2(sys)-96
ItEM DEscrIPtIon Part no. Qty Part no. Qty Part no. Qty
30 BUMPER, TRACK 1010949 1 1010950 1 1010951 1
31 BUMPER, RAIL 1010952 1 1010953 1 1010954 1
32 BUMPER, EnD CAP BM-29064 2 BM-29064 2 BM-29064 2
33 SWITCH, TOGGLE 120V/208-240V SW-33896 2 SW-33896 2 SW-33896 3
SWITCH, TOGGLE 230V SW-3528 2 SW-3528 2 SW-3528 3
SWITCH, BOOT 230V SW-3905 2 SW-3905 2 SW-3905 3
34 InDICATOR LIGHT 120V/208-240V LI-3951 2 LI-3027 2 LI-3027 3
230V LI-3951 2 LI-3951 2 LI-3951 3
35 THERMOSTAT TT-3498 2 TT-3498 2 TT-3498 3
36 TERMInAL BLOCK BK-25432 1 BK-25432 1 BK-25432 1
37 FUSE HOLDER FU-3772 1 FU-3772 1 FU-3772 1
38 FUSE, 15 AMP FU-3775 2 FU-3775 2 FU-3775 2
39* THERMOSTAT KnOB Kn-3473 2 Kn-3473 2 Kn-3473 3
40* DOOR GLIDES DR-22480F 1 DR-22480F 1 DR-22480F 1
41* DOOR BUMPER DR-22480G 1 DR-22480G 1 DR-22480G 1
MoDEl > ED2(sys)-48 ED2(sys)-72 ED2(sys)-96
ItEM DEscrIPtIon Part no. Qty Part no. Qty Part no. Qty
13 GLASS FRAME, RH black oP-26668 1 oP-26668 1 oP-26668 1
stainless steel 5001266 1 5001266 1 5001266 1
custom color 5001484 1 5001484 1 5001484 1
21 REAR TRIM black OP-26660 1 OP-26664 1 OP-26666 1
stainless steel 1002021 1 1002023 1 1002025 1
custom color 1000392 1 1002464 1 1002466 1
22 RIGHT TRIM black OP-26661 1 OP-26661 1 OP-26661 1
stainless steel 1002018 1 1002018 1 1002018 1
custom color 1002309 1 1002309 1 1002309 1
23 FROnT TRIM black OP-26659 1 OP-26663 1 OP-26665 1
stainless steel 1002020 1 1002022 1 1002024 1
custom color 1000391 1 1002463 1 1002465 1
24 LEFT TRIM black OP-26662 1 OP-26662 1 OP-26662 1
stainless steel 1002019 1 1002019 1 1002019 1
custom color 1002310 1 1002310 1 1002310 1
28 GLASS FRAME, LH black OP-26667 1 OP-26667 1 OP-26667 1
stainless steel 5001265 1 5001265 1 5001265 1
custom color 5001483 1 5001483 1 5001483 1
F u l l l I s t o F c o u n t E r - t o P P a n E l s (
s e e d r a w i n g p g
1 9 )
f u l l a s s e m b l y • f r o n t v i e w ( c o n t i n u e d )
* nOT SHOWn
