Page 17
880-N1R
880-N1R Instruction Manual
Rev. 0.0
Page 13 of 38
TXD+
TX
D
-
RXD+
REMOTE
OUTPUT
RXD-
0V
Figure 17 Main 880 terminal blocks and connections
4. Connect the RS-422 Serial communications cable to the input terminal blocks inside the 880 Remote
Display labeled “TERMINAL INPUT” as shown in (Figure 18).
TX
D+
TX
D-
RX
D+
TERMINAL
INPUT
RX
D-
0V
Figure 18 Remote RS-422 connections
0V
RXD-
REMOTE DISPLAY
RXD+
TXD+
TXD-
CUSTOMER SUPPLIED
WIRING
TXD+
TXD-
RXD+
T
E
R
M
IN
A
L
IN
P
U
T
RXD-
0V
TXD+
TXD-
RXD+
REMOT
E
OU
T
P
UT
RXD-
0V
MAIN 880
Figure 19 Remote Interconnect Wiring
5. Connect 110-220VAC input to the Fuse Block labeled “VAC (L1)” in the lower left of the enclosure.
Connect Neutral (or L2) to terminal labeled “NEU (L2)” and Ground to the Green/Yellow terminal
labeled “GROUND” (Figure 20). The power supply is able to accept AC input voltages from 100 to
240 volts at 50 or 60Hz.
