880-N1R Instruction Manual Rev. 0.0 Page 6 of 38
2.5 Specifications
Capacity
User
Configurable
Serial Units: Up to 32 serial devices
Analog Units: Up to 72 analog inputs using the Detcon DA-4 Modules
Inputs
RS-485 Modbus™ RTU
Outputs
Primary: RS-485
Slave: RS-485
Remote Output: RS-422
User Configurable Relays via the use of Detcon RL4 Modules
Power Input
100-240VAC
50~60Hz
18-30VDC
Power Consumption
Base Unit <40W – Not to include I/O Modules and sensors.
Total Power is dependent on number of I/O modules, number of sensors, and the type of sensors attached.
Total power of unit with I/O modules and gas sensors not to exceed 120 Watts.
Display
8” inch diagonal Graphic Backlit LCD Touch screen display
Electrical Classification
19” Rack Mount Enclosure
Dimensions
19''W x 10.5''H x 15''D
Operating Temperature Range
0°C to +45°C
Warranty
One
year
