Register
FC Name
40000
3
RANGE
40001
3
CONCENTRATION READING
40002
3
ALARM1 SETPOINT
40003
3
ALARM2 SETPOINT
40004
3
(not used – ignore)
40005
3
STATUS BITS
REGISTER 40005 STATUS IN UPPER BYTE
15
14
13
12
11
10
9
8
Test
Mode
REGISTER 40005 STATUS BITS IN LOWER BYTE
7
6
5
4
3
2
1
0
A2=Desc A2=Latchg Alarm2
A1=Desc
A1=Latchg Alarm1
F=Latchg
Fault
1.5
RS-485 Modbus to Host
The Modbus Register assignment as available to the Modbus Master Host communicating with the FM on
serial channel 2 is given in this section.
The first 64 registers provide the state of each Mod10 SSC module’s concentration reading and status. The
Host can get the whole group of data from one poll of the FM by getting these registers 40000 through 40063.
Modbus Register assignment.
Register
FC Name
Description
40000
40001
3
Concentration
Status bits
Slave 1: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40002
40003
3
Concentration
Status bits
Slave 2: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40004
40005
3
Concentration
Status bits
Slave 3: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40006
40007
3
Concentration
Status bits
Slave 4: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40008
40009
3
Concentration
Status bits
Slave 5: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40010
40011
3
Concentration
Status bits
Slave 6: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40012
40013
3
Concentration
Status bits
Slave 7: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40014
40015
3
Concentration
Status bits
Slave 8: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40016
40017
3
Concentration
Status bits
Slave 9: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40018
40019
3
Concentration
Status bits
Slave 10: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40020
40021
3
Concentration
Status bits
Slave 11: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
