Model 10C
10C Control Module Instruction Manual Rev.0.0 Page 6 of 14
40022
40023 3 Concentration
Status bits Slave 12: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40024
40025 3 Concentration
Status bits Slave 13: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40026
40027 3 Concentration
Status bits Slave 14: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40028
40029 3 Concentration
Status bits Slave 15: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40030
40031 3 Concentration
Status bits Slave 16: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40032
40033 3 Concentration
Status bits Slave 17: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40034
40035 3 Concentration
Status bits Slave 18: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40036
40037 3 Concentration
Status bits Slave 19: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40038
40039 3 Concentration
Status bits Slave 20: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40040
40041 3 Concentration
Status bits Slave 21: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40042
40043 3 Concentration
Status bits Slave 22: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40044
40045 3 Concentration
Status bits Slave 23: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40046
40047 3 Concentration
Status bits Slave 24: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40048
40049 3 Concentration
Status bits Slave 25: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40050
40051 3 Concentration
Status bits Slave 26: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40052
40053 3 Concentration
Status bits Slave 27: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40054
40055 3 Concentration
Status bits Slave 28: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40056
40057 3 Concentration
Status bits Slave 29: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40058
40059 3 Concentration
Status bits Slave 30: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40060
40061 3 Concentration
Status bits Slave 31: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
40062
40063 3 Concentration
Status bits Slave 32: Concentration and Status
(Fault, Alarm 1, Alarm 2 status)
The Modbus Master Host should obtain the Number of Slaves from register 41001 so that it only polls
registers up to the last Slave in the FM’s group of SSC modules.
In large configurations, to get the best reporting time at the expense of more complex programming in the
Host, the FM offers a Report By Exception (RBE) scheme.
The RBE scheme does not have to be implemented or it can be implemented at a couple of complexity levels.
The least complex RBE scheme is to poll COS registers 41002 and 41003 and only poll registers at 40000 if
