4.2.1 Latching
The Latching selection is indicated with “LT=x” in the display where “LT=0” for Latching is OFF and
“LT=1” for Latching is ON.
4.2.2 Energized
The Energized selection is indicated with “EN=x” in the display where “EN=0” for Energized is OFF and
“EN=1” for Energized is ON.
4.2.3 Silenceable
The Silenceable selection is indicated with “SL=x” in the display where “SL=0” for Silenceable is OFF and
“SL=1” for Silenceable is ON.
4.3 Modbus Address Set
The Modbus Master communicates with the FM on serial channel 2 for which the FM needs to have assigned
an RTU ID or Modbus Address. The display shows “MODBUS SET” for this item. If the ENT pushbutton is
pressed, the display shows the Modbus Address for example: “_01_”. The value is flashing to indicate it may
be changed and by using the up and down arrow keys, followed by pressing the ENT pushbutton while the
value is flashing, the new value can be set. Notice that the Modbus in given in Hexadecimal or base-16
numbers. For instance, address 15 in base 10 is indicated with “_0F_” in the display. The ESC pushbutton can
be used to escape, backup, or abort or with no further action the display will timeout.
5.0 Default Settings
Settings are saved in non-volatile flash memory but are initially set to the following values.
Number of Sensors = 1
Alarm 1, Alarm2 =
Non-Latching, Non-Silenceable, Non-Energized
Fault = Non-Latching, Non-Silenceable, Energized
Modbus ID = 01
Channel 1 Settings = 9600 Baud, 8, N, 1 (not adjustable)
Channel 2 Settings = 9600 Baud, 8, N, 1 (not adjustable)
