STEP 1A -
Important - Please Read These Instructions Carefully!
Push this lever down, then
slide the inner glide section
out of the glide assembly.
FRONT OF CART
Face of
Glide
Backside
of Glide
Use these three (3) holes to attach the glide to the side panel.
This edge will at
ta
ch to back
pa
nel in the next step.
TOP
Attach Glides to Side
Panels
1. Remove the drawer side
section of the glide by pushing
the black lever down and
sliding the steel inner glide
section all the way out of the
glide assembly. Set this inner
section aside as it will be used
later on the lower drawer
sides.
2. Next, identify the holes to be
used for attaching each glide
to the side panel. IMPORTANT
as shown below, the full
extention glides are only
attached to the right side panel
and to the center divider as
shown in Step 6.
Attach glides using 3/8” #6 pan
head screws. In step 10 you
will loosen these screws to
slide the glides flush with the
back panel once it is attached.
