(7) Data Chart
Use this data chart to record your sharpening set ups on various tools to
increase repeatability and reduce your set up time.
Tool Name
TSO
Tool Stick Out
H
Height
TBP: (A or B)
Tool Bar Position
Notes
Tip: Use a Black Marker when re-sharpening an existing angle onto a tool. Color the bevel to be
sharpened then set up the tool (with or without jig) and Tool Bar so the bevel lays flat on the
abrasive wheel. Turn the wheel by hand one half revolution. If black marker is removed at the
heel of the bevel, use Micro-Adjust Knob to raise the Tool Bar. If black marker is evenly removed,
your set up is perfect. If marker is removed only at the cutting edge, use Micro-Adjust Nut to
lower the Tool Bar. Repeat until desired grind pattern and Tool Bar Height is achieved.
