Wellsaw 1016 - Manual (Page 5)

4
Index
General
Automatic Stop 6
Blade Brushes 9
Blade Selection Guide 36-37
Feed Pressure Adjustment 7
Fixed Vise Jaw 7
Gear Box Repair 9
Hydraulic Feed Control 7
Lubrication 10
Maintenance 10
Motor Switch 9
Notes on Sawing 5
Placing Blade on Saw 7
Receiving & Installation 1
Safety Instructions 2-3
Service Kits 10
Servicing Blade Guides 8
Sliding Vise Jaw 7
Specifications 4
Trouble Shooting 5
Variable Speed Drive 7
Warranty 11
Wheel Pitch Adjustment 9
Machine Operation 12
Drawings
Frame Assembly 13
Bed Assembly 15
Blade Guide Assembly (up to S/N 2499) 17
Guide-A-Matic Assembly
17
Carbide Guide Option (up to S/N 2499) 19
Blade Guide Assembly (S/N 2500 on) 21
Coolant System 23
Leg & Chip Pan
23
Rite Tensioning Device® 25
Hydraulic System 27
Motor & Gear Box 29
Variable Speed Drive 31
Electrical Controls 33
Parts Lists & Part Numbers
Frame Assembly 14
Bed Assembly 16
Blade Guide Assembly (up to S/N 2499) 18
Guide-A-Matic Assembly 18
Carbide Guide Option (up to S/N 2499) 20
Blade Guide Assembly (S/N 2500 on) 22
Coolant System 24
Leg & Chip Pan
24
Rite Tensioning Device® 26
Hydraulic System 28
Motor & Gear Box 30
Variable Speed Drive 32
Electrical Controls 34
Specifications
Capacity:
Round 10½”
Flat 16½”
Rectangular 10" x 16"
45

10" x 9"
Blade Speeds 50-100-175-275 SFPM
Motor
2hp 208-230/460/60/3
6.5 - 6.2 - 3.1 amps
2hp 115 - 230/60/1
24 - 12 amps
Drive V-Belt
Blade Size 1" x .035 x 11'6"
Height to top of Bed 29"
Coolant Tank Capacity 8 gallons, 170 GPH
.6 Amp/115 Volt
Floor Space 30" wide x 84" long
Vise Control Manual Screw
Swivel Vise To 45

Blade Tension Manual Rite Tension®
Feed Rate Control Variable, Hydraulic
Band Wheels 15" Diameter Cast Iron
Shipping Weight 900 Lbs.
Options Available:
Variable Speed Blade Drive (70-375 SFPM)
Casters (set of 4, 2 locking)
NFPA or JIC Electrics (w/disconnect)
Totally Enclosed Motor
Work Light
Stock Stand
5' or 10' Non-Powered Conveyor
