Page 19

Blade Guide Assembly
1
155119
Coolant Assembly (see page XX)
Serial Numbers up to 2499
2
105412
Blade Guide Assembly, Idle End
(includes items 7-23)
3
105409
Blade Guide Assembly, Drive End
(includes items 7-22 and 24)
4
105367
Guide-A-Matic Assembly
(see bottom of this page)
5
105414
Roller Support Assembly, Idle End
(includes items 15-23)
6
105411
Roller Support Assembly, Drive End
(includes items 15-22 and 24)
7
105335-001
Hand Wheel and Screw
8
101453
Guide Bracket
9
100004-018
Cap Screw, HH, 5/16-18 x 1
10
100029-003
Flat Washer, 5/16
11
100034-006
Set Screw, 5/16-18 x 7/8
12
M-092
Roller Adjuster
(includes items 11 and 13)
13
100034-005
Set Screw, 5/16-18 x 3/4
14
100004-018
Cap Screw, HH, 5/16-18 x 1
15
101178
Roller Axle, Bottom
16
100416-003
Bearing, Side
17
101186
Flat Washer
18
100406-002
Bearing, Top
19
101179
Roller Axle, Top
20
101300
Eccentric Axle Nut
21
100025-002
Lock Washer, 5/16
22
105396
Roller Support, Idle End
23
101180
Roller Support, Drive End
24
100004-022
Cap Screw, HH, 5/16-18 x 1-1/2
25
M-309
Blade Brush Bracket Assembly
(before S/N 3319, includes items 28-33)
26
101615
Blade Brush Assembly (before S/N 3319)
(includes items 30-33)
27
M-198
Blade Brush Bracket
28
100034-003
Set Screw, 5/16-18 x 1/2
29
100017-001
Hex Nut, Heavy, 1/4-20
30
M-425
Blade Brush Angle
31
M-426
Blade Brush (2 req'd)
NOTE: For blade guards see page 21 and 22
Guide-A-Matic©
1
105367
Guide-A-Matic© (includes items 2-12)
2
101300
Eccentric Axle Nut
3
100025-002
Lock Washer, 5/16
4
101186
Flat Washer
5
100416-003
Bearing, Side
6
105357
Eccentric Bushing
7
105359
Torsion Spring
8
105358
Roller Axle
9
100053-025
Roll Pin, 1/16 x 5/16
10
105355
Brass Housing
11
105360
Spring
12
105356
Shoulder Screw
Page 1
18
for serial numbers after 3319, see page 13
