Electrical controls – Wellsaw 1016 User Manual
Page 35

Electrical Controls
1
100612-004
Connector, TB-2534
2A
100796-019
Hub Connector, 1/2, TB-370
2B
100796-024
Hub Connector, 3/4, TB-371
3
100240-001
Conduit Lock Nut
4
100612-002
Connector, TB-2523
5
100870
Electrical Enclosure
6
100869-005
Transformer, 230/460 Volts
100869-007
Transformer, 208 Volts
100869-006
Transformer, 575 Volts
7
100000-017
Machine Screw, RH 10-32 x 1/4
8
100628-017
Fuse, FNA 2-1/2 Amp
9
155115
Fuse Block Ass'y
(used w/ 115/60/1 only)
10
100796-010
Ground Screw, 10-32 x 3/8
11 * 100867
Magnetic Starter 3ph for EARLIER saws
100867-018
Magnetic Starter 1ph for EARLIER saws
* SEE NOTE
12
100888-B32
Heater, B32 115/60/1 (1 req'd)
100888-B14
Heater, B14 230/60/1 (1 req'd)
100888-B102
Heater, B10.2, 208/60/3 (3 req'd)
100888-B102
Heater, B10.2, 230/60/3 (3 req'd)
100888-B415
Heater, B41.5 460/60/3 (3 req'd)
100888-B210
Heater, B21.0 575/60/3 (3 req'd)
13
098048-050
Gasket, SC 41, 1/8 x 3/4 x 50"
14
100000-041
Machine Screw, RH 10-32 x 1/2
15
155118
Frame Rest Ass'y, w/ cord
(Includes items 17 thru 24)
16
155118-001
Frame Rest w/ Trip Bar
(Includes items 17 thru 19)
17
105977
Frame Rest
18
150344
Switch Bar Weldment
19
100165-005
Shoulder Bolt, 5/16 x 3/4
20
100782-012
Limit Switch, 115v w/ screws
* NOTE: Various starters were used on this saw.
21
100606-001
Sealing Ring
to make certain you receive the correct replacement
22
100612-006
Elbow, 90 deg, TB-2268
parts, contact the Wellsaw parts department with the
23
100015-005
Hex Nut, 6-32 (2 req'd)
information on your saw's starter.
24
100026-001
Washer, Shake Proof, #6 (2 req'd)
27
155094
Switch Box
28
155117
Control Switch Ass'y
(includes items 29 thru 35 and 14)
29
155095
Switch Box Cover
30
150230
Legend Plate
31
100871-003
Selector Switch, Coolant -for s/n before 4041, order 100871-004 too.
32
100871-001
Push Button Start -for s/n before 4041, order 100871-004 too.
33
100871-013
Push Button Stop -for s/n before 4041, order 100871-005 too.
34
100871-004
Switch Block, Coolant or Start -for s/n before 4041, order switch too.
35
100871-005
Switch Block, Stop -for s/n before 4041, order 100871-013 too.
37
100893
Back Panel
36
100892
Enclosure Cover
*NEW STARTERS
for after s/n 5235
11
100867-029
IEC Starter 3 ph
100867-023
IEC Starter 1 ph
Adjustable Overload for IEC Starters (check motor amps)
100867-011
2.5-4 amps 440-460V
100867-013
5.5-8 amps 208-230V 3ph
100867-027
9-13 amps 208-230V 1ph
100867-022
16-24 amps 110-120V
100717-016T4
Mounting rail
34
