Blade Guide Assembly
Serial Number 2500 and Later
1
155124
Blade Guide Assembly, Drive End
(includes items 5-27, and 29, minus 7 and 12)
2
155125
Blade Guide Assembly, Idle End
(includes items 5-28, minus 6 and 11)
3
152160-001 Guide Support Assembly, Drive End
(includes items 13-27 and 29)
4
152161-001 Guide Support Assembly, Idle End
(includes items 13-28)
5
105335-001
Hand Wheel and Screw
6
155123
Roller Guide Bracket, Drive End
7
155122
Roller Guide Bracket, Idle End
8
100004-018
Cap Screw, HH, 5/16-18 x 1
9
100029-002
Flat Washer
10
152155
Vertical Adjusting Block
11
152121-003
Horizontal Adjusting Block, Drive End
12
152121-002
Horizontal Adjusting Block, Idle End
13
152151
Adjusting Bolt
14
100053-036
Roll Pin, 1/4 x 2
15
152153
Carbide Back-up Guide
16
100023-006
Hex Nut, Nylon Lock, 1/4-20
17
152156
Adjusting Knob
18
100136-009
Spring
19
152157
Stud
20
106317
Fixed Carbide Guide (2 req'd per blade guide)
21
100008-004
Cap Screw, SH, 5/16-18 x 5/8
22
B-109
Eccentric Roller Axle
23
100416-001
Bearing, Side (2 req'd per blade guide)
24
100097-001
Roller Guide Washer
25
100027-005
Lock Washer, Shakeproof, 5/16
26
101300
Hex Nut, 5/16-18
27
B-043
Roller Axle
28
152120
Guide Support, Idle End
29
152119
Guide Support, Drive End
30
100324-009
Hose Barb, 1/4: hose, 90 deg.
31
100219-003
Hose Clamp, 1/4"
32
100350-068
Coolant Hose, Idle End
33
100350-036
Coolant Hose, Drive End
34
105551
Blade Guards, Complete, D.E. & I.E.
(includes items 35- 48 )
35
105563
Blade Guard Ass'y Complete I.E.
(includes items 10, and 37-45)
36
105564
Blade Guard Ass'y Complete D.E.
(includes items 44-48)
37
105537
Spacer (before S/N 2500)
38
100004-019
Cap Screw, HH, 5/16-18 x 3/4
39
105536
Mounting Bracket, I.E.
40
100000-024
Machine Screw, RH, 1/4-20 x 3/8
41
100097-002
Flat Washer, 1/4
42
105535
Blade Guard, Upper, I.E.
43
105539
Blade Guard, Lower, I.E.
44
105550
Hinge
45
100131-003
Pop Rivets
46
105552
Mounting Bracket, D.E.
47
105554
Blade Guard, D. E. (2 req'd)
48
100000-018
Machine Screw, RH, 10-32 x 3/8
