Wellsaw 1016 User Manual
Page 11

Preventive Maintenance
Caution: Disconnect the electrical supply and press
emergency STOP button before performing any
maintenance. DO NOT service the Frame Hydraulic
Cylinder or Down Feed Valve unless the frame is in the
DOWN position or resting on a mechanical stop, such as a
block of wood.
D a i l y
1. Keep the saw clean and free of chips.
2. Maintain the coolant level and keep the coolant tank and
filter clean of chip accumulation or sludge.
M o n t h l y
1. Check, adjust and replace blade brush as needed.
2. Lubricate drive gears
3. Inspect carbide guides and bearings.
4. Inspect drive belt.
5. Clean coolant tank and filter as needed.
Annually
1. Check hydraulic oil level.
2. Replace guide rollers and carbide inserts.
3. Inspect gear box. Lubricate as needed.
Lubrication
Correct and adequate lubrication is a very important factor
in determining the life and service of your Wellsaw. It is
essential that all dust, dirt, chips,
etc. be
thoroughly
removed before lubricating the saw. The following
lubrication recommendations cover usual saw applications.
Heavy use and hostile environments may indicate more
frequent lubrication for best saw performance.
Vise Screw, Ring Gear, Drive Pinion
1. Inspect Monthly.
2. Use anti-seize on Vise Screw
3. Use an Extreme Pressure open gear lube sparingly on
Ring Gear and Drive Pinion
Gear Case
1. Inspect after 3 years (6,000 hours).
2. Use Mobilgrease XHP 220 or equivalent.
Hydraulic Cylinder
1. Inspect annually. Fill to top of plug. Drain and replace
every 5 years (10,000 hours).
2. Fill with Mobil Velocite Oil #6 or equivalent.
3. Viscosity at 100EF: SUS 57-61.
4. Military Specification: None.
M o t o r
1. Inspect annually. Re-lubricate every 2 years (4,000 hours)
1 to 2 full strokes.
2. Use Shell Dolium R or equivalent.
3. Viscosity: Heavy Grease, drop point 219EC.
4. Military Specification: None.
Recommended Service Kits
For Insurance
Against Downtime
Up to S/N 2499
1 year
M-426 Blade
Brush
2
req’d.
2 year
100406-002 Top
Bearing
2
req’d.
100416-003 Side
Bearing
4
req’d.
100053-025 Roll Pin, Guide A Matic 4 req’d
100066-005 V-Belt
1
req’d.
M-426 Blade
Brush
2
req’d.
M-166
Dash Pot Cup Leather
1 req’d.
After S/N 2499
1 year
M-426 Blade
Brush
2
req’d
2 year
100416-001 Side
Bearing
4
req’d.
100066-005 V-Belt
1
req’d.
M-426 Blade
Brush
2
req’d.
100133-004 Blade
Brush
(after s/n 3329)
1 req’d.
Note: Check Carbide Guides
1 0
