Carbide Guides
Up to Serial Number 2499
(option)
1
101522-002
Blade Guide Assembly, D.E.
(includes items 5-27 minus 13)
2
105406-002
Blade Guide Assembly, I.E.
(includes items 5-27 minus 12)
3
150061
Guide Support Assembly, D.E.
(includes items 12-27 minus 13)
4
106659
Guide Support Assembly, I.E.
(includes items 13-27)
5
105335-001
Hand Wheel & Screw
6
101453
Guide Bracket
7
100034-006
Set Screw, 5/16-18 x 7/8
8
100034-005
Set Screw, 5/16-18 x 3/4
9
M-092
Roller Adjuster
10
100004-018
Cap Screw, HH, 5/16-18 x 1
11
100029-002
Flat Washer, 1/4
12
106389
Roller Support, D.E.
13
106315
Roller Support, I.E.
14
100008-018
Cap Screw, SH, 5/16-18 x 3/4
15
106317
Fixed Carbide Guide
16
106319
Spring Backed Carbide Guide
17
101300
Eccentric Axle Nut
18
100004-016
Cap Screw, HH, 5/16-18 x 7/8
19
100029-003
Flat Washer, 5/16
20
101186
Roller Guide Washer (3 req'd)
21
100416-003
Bearing, Side (2 req'd)
22
101178
Roller Axle
23
101177
Eccentric Roller Axle
24
100127-003
Set Screw, Nylon Point, 1/4-20 x 5/16
25
106285
Guide Pre-load Assembly
26
101179
Roller Axle, Top
27
100406-002
Bearing, Top
28
100220-040
Coolant Hose
29
100219-001
Hose Clamp
30
102617
Hose Adapter
31
100226
Needle Valve
32
101670
Coolant Nozzle
33
100246-001
Pipe Strap
34
100000-018
Machine Screw, RH, 10-32 x 3/8
Note: In The Blade Guide Assembly Illustration, Item 12, is the Drive End Assembly.
For the Idle End Assembly, order item 13. All Other Parts are Interchangeable.
